My brother is visiting us from overseas and I thought it would be cool to set up some kind of a retro gaming environment we could use to refresh our memories from childhood when we spent hours playing M.U.L.E., Kikstart 2 or HatTrick on our Commodore 64. Raspberry Pi seemed a perfect choice – it’s close to the TV (or already connected if you are using Raspbmc) and it has access to the network which makes it easy to acquire software. To play games however you need some kind of a controller. So, what else is close to the TV? An XBox! And it actually has some controllers (let’s forget about Kinect for now). And this is how I came up with the idea of something I called:

– a Commodore 64 emulator running on Raspberry Pi and using XBox 360 controllers. Setting things up turned out to be relatively easy. First you need to install Vice emulator. You can find some steps here but they don’t actually work. Firstly they refer to the “squeeze” distro and you most likely have the “wheezy” distro (the “regular” Raspbian image recommended on the Raspberry Pi download page). Secondly the Raspbian “wheezy” image is a hard float image and when running Vice installed from ftp.uk.debian.org it just dies with the Segmentation Fault error. After my last battle with Raspberry Pi, Mono and EF6 I think it might be possible to install the package from ftp.uk.debian.org on the Soft-float Debian “wheezy” distro but this distro is a bit slower so I kept looking for a version I could run directly on Raspbian. Soon I found this thread which points to something that seems like a private version of Vice built for armhf architecture. If you just follow the steps (btw. notice the _armhf suffix in the Vice package – the package from ftp.uk.debian.org does not have this suffix and I believe this is the reason it doesn’t work on Raspbian):

wget http://www.frank-buss.de/raspberrypi/vice_2.3.dfsg-4_armhf.deb
dpkg -i vice_2.3.dfsg-4_armhf.deb
wget http://www.zimmers.net/anonftp/pub/cbm/crossplatform/emulators/VICE/old/vice-1.5-roms.tar.gz
tar -xvzf vice-1.5-roms.tar.gz
cp -a vice-1.5-roms/data/* /usr/lib/vice/

you will end up with a working C64 emulator on your Raspberry Pi (don’t forget to copy ROMs or you will have an opportunity to see yet another Segmentation Fault error – verified empirically). Just run a console window in the X Window environment and start Vice emulator with the x64 command.
[Spoiler Warning] Had I run any game at this point I would probably have given up setting up the controllers but I did not and instead[/Spoiler Warning] I moved on to setting up the controllers. It seemed to be very easy. There is this xboxdrv thingy you install and stuff should just work (note: you will need the XBox 360 controller “for Windows” – it contains a standalone USB receiver which you will need to plug into your Raspberry Pi (your “Windows” today)). To install xboxdrv you just need to run the following commands:

sudo apt-get update
sudo apt-get install xboxdrv

Just to see if/that the controller works I started the xboxdrv and turned on verbose output

sudo xboxdrv --v

synced the controller and started pressing buttons and pushing sticks. Unfortunately I did not see any activity on the screen. I “reset” the controller (i.e. removed and replaced batteries) pressed the button on the receiver to initiate syncing and turned on the controller. Again it synced fine but I could not see any activity in the xboxdrv window regardless of what I did to the controller. I even restarted my Raspberry Pi and repeated the process but it still did not help. I found a small app called jstest-gtk that allows testing joysticks but it could not find any controllers attached. I learnt about a few interesting debugging options built in xboxdrv (like debugging at the USB protocol level) but this did not help much. With that I started thinking that it must have been a problem with the controller so I grabbed a different one turned it on and… it synced immediately. That was unexpected since I did not press the sync button on the receiver. This is when I realized that the Problem Existed Between Chair And Keyboard (PEBCAK). I had been trying to sync the controller by pressing the button on the receiver but had not pressed the sync button on the controller itself. Therefore the controller started the Xbox located in a different room and then was syncing with it rather than with the receiver connected to the Raspberry Pi. A complete fail on my side. It took me a while to get over my lameness but when I did the things went smoothly. I disconnected my Xbox and really synced my controller with the receiver connected to my Raspberry Pi. xboxdrv woke up and jstest-gtk finally showed that there is a controller present. I configured Vice to use arrow keys as joystick and space as the fire button. The only remaining thing was to map the controller joystick and button(s). This is not difficult and can be done just by providing parameters when starting xboxdrv – just like this:

sudo xboxdrv –ui-axismap x1=KEY_LEFT:KEY_RIGHT,y1=KEY_UP,KEY_DOWN –ui-buttonmap a=XK_space

I started the emulator and ran a game. The controller worked fine – I was able to use it but I was not really able to play any game. Vice was way too slow – games ran just at 5-7 frames per second and the terminal window I used to start Vice from constantly showed the message:

Warning – Your machine is to slow for current settings

I played for 10 more minutes and gave up. That’s too bad. I still don’t quite understand why Raspberry Pi is not able to handle this. I ended up digging up the original Xbox from my garage. It has an ancient version of XBMC but with a working Commodore 64 emulator. We used it instead of Raspberry Pi. Unfortunately when playing M.U.L.E. pirates helped my brother by stealing all my smithore twice (the second time in the 11th round) and I lost the game. It probably would not have felt that bitter had it happened on Raspberry Pi.
